| PMDC MOTOR Technical Data | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage(V) | No-Load | Rated | ||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | ||
| RPM | A | RPM | A | mN.m / gf.cm | W | ||||
| RS-550H | 23128R | 6.0~24.0 | 24VDC | 4500 | 0.1 | 3932 | 0.39 | 25.7/262 | 10.6 |
| 6034 | 6.0~12.0 | 12VDC | 16000 | 1.12 | 13613 | 4.96 | 25.6/261.3 | 40.36 | |
| RS-555H | 3540 | 6.0~12.0 | 12VDC | 7800 | 0.3 | 6708 | 1.84 | 21.9/223.4 | 15.35 |
| 23100 | 6.0~24.0 | 24VDC | 7000 | 0.14 | 6004 | 0.77 | 19.2/195.8 | 12.09 | |
What are the primary applications for RS 550, 545, and 555 DC motors?
These high RPM DC motors are widely utilized in power tools, home appliances, automotive components, smart devices, and custom DIY projects requiring dependable speed and torque.
What is the typical voltage range for these PMDC motors?
They operate within a flexible range of 6V to 24V DC, allowing adaptation to various power configurations depending on the specific model specifications.
Can the technical specifications of the motors be customized?
Yes, technical parameters including operating voltage range, rated speed (RPM), torque performance, and shaft design can be adjusted to meet your project requirements.
How do I choose between the RS-550 and RS-555 models?
The RS-550 is optimized for higher RPM requirements (up to 30,000 RPM), while the RS-555 generally provides balanced torque and power efficiency at moderate speeds. Review the technical table for exact performance metrics.
Do these motors support bidirectional rotation?
Yes, as Permanent Magnet DC (PMDC) motors, changing the polarity of the input voltage wires will reverse the rotation direction.
Are these motors suitable for heavy-duty industrial tasks?
They are highly durable for their class. For intensive or continuous high-load applications, implementing proper cooling mechanisms or heatsinks is recommended to prolong motor life.
