390 Dc Motor for Machine Fan From Shenzhen Supplier 12v 6000rpm Motor

Send Inquiry

Product Description

390 DC Motor for Machine Fan 12V 6000RPM Motor

Product Details

🛠️ Motor Customized Specification, Please contact us to get tailored solutions.

Reference Drawings

RS - 365

RS - 385

RS - 395

📐 The length of the shaft can be customized upon request. Please contact us for details.

Reference Datasheet

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	A	RPM	A	mN.m / gf.cm	W	A	mN.m / gf.cm
RS-390SH	20156R	6.0~12.0	12VDC	5000	0.08	4243	0.33	6.07 / 61.9	2.72	2.22	42.2 / 430
RS-390SH	2975	6.0~12.0	12VDC	12000	0.29	10165	0.33	5.75 / 58.6	1.31	8.9	80.4 / 820
RS-395SH	15130	6.0~12.0	12VDC	3650	0.66	2949	0.25	5.83 / 59.5	1.8	1.06	30.4 / 310
RS-395SH	15100R	6.0~24.0	24VDC	10300	0.07	8893	0.38	7.09 / 72.3	6.68	2.66	54.9 / 560

Product Gallery

Frequently Asked Questions (FAQ)

Q1: What are the main applications for the RS-390/RS-395 DC motor series?

A1: These PMDC motors are widely used in machine fans, cooling fans, small home appliances, personal care devices, power tools, and various customized automated mechanical structures that require stable high-speed performance.

Q2: Can I customize the shaft length and electrical specifications of these motors?

A2: Yes. The shaft length, shaft type (D-cut, round, threaded), rated voltage, speed, and torque parameters can be customized according to your specific project needs.

Q3: What is the typical operating voltage range for these DC motors?

A3: The RS-390 and RS-395 motor series typically operate in a range from 6.0V to 24.0V DC, depending on the specific model winding design. Common nominal voltages include 12VDC and 24VDC.

Q4: How do the RS-365, RS-385, and RS-395 models differ?

A4: These models differ in body dimensions, torque outputs, and power ratings. The RS-395 series generally offers higher torque and power capacity compared to the RS-365 and RS-385 series within the same operating voltage.

Q5: Are these motors suitable for high-speed operation?

A5: Yes. For instance, the RS-390SH (Model 2975) can reach no-load speeds up to 12,000 RPM at 12VDC, making it highly suitable for applications requiring rapid airflow or high rotational speeds.
