Motor Customized Specification, Please contact us.
RS - 365
RS - 385
RS - 395
The length of shaft can be customized, Please contact us.
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed (RPM) | Current (A) | Speed (RPM) | Current (A) | Torque (mN.m / gf.cm) | Power (W) | Current (A) | Torque (mN.m / gf.cm) | ||
| RS-390SH | 20156R | 6.0~12.0 | 12VDC | 5000 | 0.08 | 4243 | 0.33 | 6.07 / 61.9 | 2.72 | 2.22 | 42.2 / 430 |
| 2975 | 6.0~12.0 | 12VDC | 12000 | 0.29 | 10165 | 0.33 | 5.75 / 58.6 | 1.31 | 8.9 | 80.4 / 820 | |
| RS-395SH | 15130 | 6.0~12.0 | 12VDC | 3650 | 0.66 | 2949 | 0.25 | 5.83 / 59.5 | 1.8 | 1.06 | 30.4 / 310 |
| 15100R | 6.0~24.0 | 24VDC | 10300 | 0.07 | 8893 | 0.38 | 7.09 / 72.3 | 6.68 | 2.66 | 54.9 / 560 | |
What are the typical applications for the RS-380 and RS-385 micro DC motors?
These micro DC motors are widely used in high-speed, high-torque applications including electric drills, garden power tools, dynamic toy models, home appliances, and various smart DIY projects.
Can the output shaft length and specifications be customized?
Yes, we support full customization of the motor's shaft length, nominal voltage range, RPM performance, and other parameters to perfectly align with your specific device requirements.
What voltage range do these micro motors operate under?
The standard operating voltage ranges from 12V to 24V DC. However, depending on the model chosen and your application needs, the operating range can stretch from 6.0V up to 24.0V.
What maximum speeds can these micro motors achieve?
Under nominal operating voltage configurations, these high-speed motors can achieve rotation speeds of up to 13,000 RPM, providing steady and powerful torque output.
How can I choose the best motor model for my product?
Please review the technical datasheet for comparisons on Operating Range, Rated Speed, Torque, and Stall Current, or get in touch with our design support team with your design criteria for recommendations.
